The Lippert Range
Kit 8 – (1813mm high x 910mm deep x 2400mm wide)
Lippert Components are the largest supplier of Slide Out Systems to the US RV Market. Started in
1957, their longevity in the RV industry stands as a testament to the quality workmanship
that goes into each kit.
Lippert come up with ready-to-use In-Wall™
Slide Out Systems provide more living space to RV consumers without compromising overall size.
Durable & Corrosion Resistant
Lightweight anodized aluminum resists rust better than systems with chains, cables and exterior mounting brackets.
Slide-Out mechanism fits inside the wall cavity leaving significantly more interior space.
Other bulky systems require a slide room fascia to cover motor and pulleys.
The 50/50 power split ensures both slide room sides properly compress seals. Independent side
control allows different stroke lengths to compensate for bulb seals setting or wearing down unequally.
Lightest slide system on the market keeps overall RV weight down.
The In-Wall Slide-Out System never needs complicated adjustments.
Smart Control Technology
Smart system continually monitors motors for safe operation, and stops the slide-out if an issue is detected.
Each Slide Out System (per side) consists of: x1 Motor Drive, x2 Drive Gears and x1 Torque Shaft, plus controller, wiring harnesses and rubbers and rollers (everything you need).
Can be installed on RVs with a wall thickness of 25 – 38mm
Has a manual override function
Switch is mounted internally (to move room in or out)
